Jim Henry Auditorium

Sound System

Mixer:
Behringer X32

Processing Gear:
Ashly Audio ne4800 Network-Enabled Protea DSP Processor

Amplifiers:
(2) Crown CH/Series
(1) Ashly PE-1800 Series

Input Devices:
(2) Shure ULX Wireless Lapels
(2) Shure ULX Wireless Handhelds
Wired Microphones: Available upon request

Speakers:
Main Speakers: (3) JBL MS28
Loudspeaker

Delay Fills:
(15) JBL Control 24CT; (4) JBL Control 19CS

Video System

Projector:
(2) Eiki LC-XL 100 – 5000 Lumens
Native Resolution 4:3

Screen:
(2) Da-Lite 7’ x 5’3”

Video Sources:
*Video sources may be added depending on switching inputs and availability of equipment.

Video Line Locations:
(1) Stage Input
(1) Sound Booth Input

Video Switching Gear:
(1) Kramer VP-729 Scaler/Switcher

Lighting System

Console:
LSC Stage Setter 8 Channel with DMX Wireless Transmitter

Non-moving fixtures:
(2) Par 46 Can Lights
(2) American DJ MEGA Panel LED
 (1) Rockville ROCKPar 50

Lighting System Technical Notes:

Our lighting fixtures are set up so that we may effectively serve all events we host. As such, we do not offer an option to move these fixtures.

Special Equipment Brought in by Performers

It is possible to use your own equipment or complete sound system in Jim Henry, but we do not recommend this option since we are unable to supply any power except the 110 volts that is found on stage.

Technical Notes

1. Other video configurations may be considered if time allows before AND after an event. When events are scheduled closely together, it is difficult to re-configure the video system, but we will work with the Event Planner to find the best solution possible.
2. Other computers may be brought in for PowerPoint or some other presentation program. You must bring your own VGA adapter if a Mac is being used.

Lighting Technical Notes

The auditorium is not equipped with a lighting bar. Only the house lighting is available.

Emergency Situations

In case of power failure, an emergency generator will power a few emergency auditorium lights and exit lights. The generator does not supply electricity to the sound and stage lighting. North Carolina State law requires Event Planners to notify event attendees of the location of emergency exits in their meeting space.

Jim Henry Statistics

Interior Dimensions (rear wall to backstage wall x sidewall to sidewall) — 59’ 6” X 48’ 8”
Ceiling Height (from floor to center of roof) — 11’ 9”
Seating Capacity — 214

Stage Area

Height of Stage from Main Floor — 1’ 9”
Full Stage Depth (center edge of stage to back wall) — 10’ 2”
Full Stage Width — 39’
Stage Ceiling Height — 10’
Video Projection Screen Size (2) — 7’ X 5’ 3”

Jim Henry Auditorium Technical Form

This completed form must be returned to your Event Coordinator at least two weeks prior to your event in order for our team to fulfill the needs of your event.
